Common Applications for Master Bond UV Curable Potting Compounds
Master Bond UV curable potting compounds have excellent bond strength to metals, ceramics and most plastics. Typical potting applications include:
- Sensors
- Capacitors
- Connectors
- Detectors
- Inductors
- Switches
- Relays
Additionally, UV curable systems have "unlimited" working life, eliminate waste and can be used for tamper proofing. Grades feature toughness, optical clarity and non-yellowing properties.
Popular UV Curable Potting Compounds
![]() |
UV15-7SP4 Single component, flexible UV cure compound. Low viscosity of 800 to 1,500 cps. Outstanding non-yellowing properties. Superior electrical insulation characteristics. Fast curing. Withstands thermal cycling. Can cure up to 1/4 inch thick. 100% reactive. Serviceable from -80°F to +250°F. |
![]() |
UV18Med USP Class VI and ISO 10993-5 approved system. Outstanding chemical and water resistance. Excellent electrical insulation properties. Rapid curing. Fast fixture times. Optically clear. Ideal for high production applications. Serviceable from -60°F to 250°F. |
![]() |
UV15DC80 UV and heat curable epoxy formulation. Cures in "shadowed out" areas at temperatures as low as 80°C. Convenient no mix system. Serviceable from -80°F to +350°F. Superb electrical insulator. |
![]() |
UV15X-6Med-2 UV curing system with high flexibility that is biocompatible per USP Class VI testing. Medium viscosity. Superior abrasion resistance. Non-yellowing. Reliable thermal and electrical insulator. Serviceable from -80°F to +250°F. |
