Two part, thermally conductive, electrically insulative epoxy for bonding and sealing featuring outstanding heat resistance; requires oven curing

Key Features

  • Combines toughness and high Tg
  • Meets NASA low outgassing specifications
  • Withstands 1,000 hours 85°C/85% RH
  • Excellent physical properties and dimensional stability

Product Description

Master Bond Supreme 46HT-1AO is a two component high performance epoxy offering good thermal conductivity, electrical isolation, and high temperature resistance. The mix ratio is a forgiving 100 to 35 by weight. The working life for a 100 gram mass is 24-48 hours. The sytem requires heat for curing. A good curing schedule to optimize properties is 2 hours at 300°F, followed by 3-4 hours at 350-400°F. After mixing, the consistency of this epoxy is a smooth, thixotropic paste. The most outstanding property is its temperature resistance.

Supreme 46HT-1AO bonds well to a wide variety of substrates including metals, composites, glass, ceramics and many plastics. It is a toughened system and can withstand rigorous thermal cycling. It is a high modulus system with exceptional compressive strength. It is chemically resistant to oils, water, fuels, acids, bases, and solvents. While it is a good conductor of heat, it is still electrically insulating. The service temperature range extends from -100F to +550°F. The color of Part A is tan and Part B is dark brown.

Supreme 46HT-1AO is a candidate for use in challenging applications in electronic, aerospace, specialty OEM and other industries where these special product properties are needed.

Product Advantages

  • Forgiving mix ratio, 100 to 35 by weight
  • Especially long working life of 24-48 hours
  • Reliable thermal conductor and electrical insulator
  • Toughened system, resists thermal cycling
  • Recommended for bonding dissimilar substrates
  • Filled system, exceptional dimensional stability
  • High glass transition temperature

Industrial Certifications


ASTM E595 Compliant

1,000 Hours at 85°C/85% RH

Meets EU Directive 2015/863

Packaging


Cans

Pails

Supreme 46HT-1AO is available is various sizes and units to accommodate customer's needs.
